Master Commercial Kitchen Power Layouts: Analyze & Design

Overview

Learners will analyze electrical loads, interpret technical symbols, apply wiring standards, and design accurate power distribution layouts for commercial kitchens. This course equips learners with the practical skills needed to confidently plan and document electrical systems using real project data. Through step-by-step video lessons, learners explore wattage calculations, tag numbering, switch placement, socket mapping, equipment load analysis, schematic diagram development, and viewport configuration inside AutoCAD. By completing the course, learners gain the ability to create safe, efficient, and code-aligned electrical layouts that meet the high-demand requirements of commercial kitchen environments. What makes this course unique is its hands-on case study approach, allowing learners to follow a real-world electrical design workflow from concept to documentation. Instead of theory alone, learners experience the complete process of designing a commercial kitchen’s power distribution system—ensuring practical, job-ready skills. Whether pursuing a career in electrical design, MEP drafting, or AutoCAD-based layout planning, learners will leave with a strong foundation and a thoroughly documented project they can reference in professional settings.

Syllabus

Foundations of Commercial Kitchen Power Design

This module introduces learners to the foundational elements of designing an electrical power distribution layout for a commercial kitchen. Through an understanding of project scope, wattage calculations, tag numbering, switch placement, socket connections, and power point legends, learners develop the core skills needed to map equipment requirements and prepare accurate electrical drawings. The module builds the essential groundwork required for safe, efficient, and compliant commercial kitchen electrical planning.

Advanced Layouts and Documentation Techniques

This module guides learners through advanced elements of electrical layout creation, including equipment load integration, schematic diagram development, and professional documentation practices using AutoCAD. By exploring power distribution sections, load balancing, viewport configuration, and title block alignment, learners gain the skills required to prepare polished, industry-standard electrical drawings for commercial kitchen installations.
